Table 4.4.8.3-1 SIP CO ATTRIBUTES
ATTRIBUTE
DESCRIPTION
RANGE
DEFAULT
P-Asserted-ID
The Id in the “P-Asserted Id” header of SIP messages can be
based on the calling station, the User Id, or a fixed User ID.
 Extension SIP User Id: one of three SIP User Tables
indicates the assigned station in PGM 111. Select which of
three in the SIP UID Selection below.
 Extension outgoing CLI: the CLI configured for the station
through Web PGM 113 and 151.
 Authorized Representative ID: the User Id of the
“Authorized Representative ID” assigned to the SIP User Id
that is indexed to the station in PGM 111. The specific index
is selected below as the SIP UID Selection.
 Fixed Table: the SIP User ID from the SIP UID Fixed Table
Index attribute is assigned below.
Refer to
description
Extension
SIP-User-ID
Table
P-Asserted-ID
Display
The “Display” field of the “P-Asserted Id” header can be
configured to use the below:
 System Rule:
- a. P-Asserted ID = Extension SIP User-ID Table, display
Contact Display Name from PGM 126, otherwise display
Station Name from PGM 111 or blank
- b. P-Asserted ID = Extension Outgoing CLI, display
Station Name from PGM 11 or blank
- c. P-Asserted ID = Authorized Rep Id, display Contact
Display Name of Authorized Rep Id from PGM 126
otherwise display Station Name from PGM 111 or blank
- d. P-Asserted ID = Fixed Table display Contact Display
Name from PGM 126 or Station Name from PGM 111 or
blank
 Extension outgoing CLI: the CLI configured for the station
through Web PGM 113 and 151.
Refer to
description
SYS RULE
Contact ID
The Id in the “Contact ID” header of SIP messages can be based
on the calling station, the User Id, or a fixed User ID.
 Extension SIP User Id: one of three SIP User Tables
indicates assigned to the station in PGM 111. Select which of
three in the SIP UID Selection below.
 Extension outgoing CLI: the CLI configured for the station
through Web PGM 113 and 151.
 Fixed Table: the SIP User Id from the SIP UID Fixed Table
Index attribute assigned below
Refer to
description
Extension
SIP-User-ID
Table
Remote-Party-
ID
The Id in the “Remote-Party ID” header of SIP messages can be
based on the calling station, the User Id, or a fixed User Id.
 Extension SIP User ID: one of three SIP User Table indices
assigned to the station in PGM 111. Select which of three in
the SIP UID Assignment section below.
 Extension outgoing CLI: the CLI configured for the station
through Web PGM 113 and 151.
 Fixed Table: the SIP User ID from the SIP UID Fixed Table
Index attribute is assigned below.
Refer to
description
Extension
SIP-User-ID
Table
