iPECS eMG80/100& eMG800 & UCP & vUCP
Administration and Programming Manual Issue 2.5
260
Table 4.4.8.3-1 SIP CO ATTRIBUTES
ATTRIBUTE
DESCRIPTION
RANGE
DEFAULT
Offnet Call Route ID Transit
CO to Offnet Direct Call Route
The below applies to calls routed from a CO/IP Line to an Off-net location by the system over a SIP Trunk.
From/Contact
ID
The ID in the “From” and “Contact” headers of SIP messages
employ System Attendant CLI, the original CLI, or a fixed User Id.
 Sys Atd: the CLI configured for the System Attendant
through Web PGM 113 and 151.
 Original CLI: the CLI received by the system for the original
incoming call.
 Fixed Table: the SIP User ID from the SIP UID Fixed Table
Index attribute is assigned below.
Refer to
description
SYST ATD
From Display
The “Display” field of the “From” header can be configured to use
the below:
 System Rule:
- a. From ID = System Atd, display Contact Display Name
from PGM 126, otherwise display Attendant Station Name
from PGM 111 or blank.
- b. From ID = Original CLI, display the Name received by
the system for the original call.
- c. From ID = Fixed Table display Contact Display Name
from PGM 126 or Station Name from PGM 111 or blank.
 Original CLI: the CLI received by the system for the original
incoming call.
Refer to
description
SYS RULE
P-Asserted-ID
The ID in the “P-Asserted ID” header of SIP messages can be
based on the System Attendant, the Original CLI, or a fixed User
ID.
 Sys Atd: CLI: the CLI configured for the System Attendant
through Web PGM 113 and 151.
 Original CLI: the CLI received by the system for the original
incoming call.
 Fixed Table: the SIP User Id from the SIP UID Fixed Table
Index attribute assigned below.
Refer to
description
SYST ATD
