iPECS eMG80/100& eMG800 & UCP & vUCP
Administration and Programming Manual Issue 2.5
261
Table 4.4.8.3-1 SIP CO ATTRIBUTES
The “Display” field of the “P-Asserted Id” header can be
configured to use the below:
System Rule:
- a. P-Asserted ID = System Atd, display Contact Display
Name from PGM 126, otherwise display Attendant Station
Name from PGM 111 or blank.
- b. P-Asserted ID = Original CLI, display the Name
received by the system for the original call.
- c. P-Asserted ID = Fixed Table display Contact Display
Name from PGM 126 or Station Name from PGM 111 or
blank.
Original CLI: the CLI received by the system for the original
incoming call.
The Id in the “Remote-Party ID” header of SIP messages can be
based on the System Attendant, the Original CLI, or a fixed User
ID.
Sys Atd: the CLI configured for the System Attendant
through Web PGM 113 and 151.
Original CLI: the CLI received by the system for the original
incoming call.
Fixed Table: the SIP User ID from the SIP UID Fixed Table
Index attribute is assigned below.
The Id in the “Diversion” header of SIP messages can be based
on the System Attendant, the Original CLI, a fixed User ID, or
Unused.
Unused: no Diversion header provided.
Sys Atd: the CLI configured for the System. Attendant
through Web PGM 113 and 151.
Original CLI: the CLI received by the system for the original
incoming call.
Fixed Table: the SIP User ID from the SIP UID Fixed Table
Index attribute is assigned below.
Offnet Call Forward by Station
The below apply to calls routed from a CO/IP Line to an Off-net location by a station over a SIP Trunk.
The Id in the “From” and “Contact” headers of SIP messages
employ the forwarding Station, the original CLI, or a fixed User ID.
Extension: the Extension SIP User ID or Extension
Outgoing CLI as assigned for the From ID under ID
Individuality.
Original CLI: the CLI received by the system for the original
incoming call.
Fixed Table: the SIP User ID from the SIP UID Fixed Table
Index attribute is assigned below.
