iPECS eMG80/100& eMG800 & UCP & vUCP
Administration and Programming Manual Issue 2.5
95
Table 3.3.3.2-1 STATION ATTRIBUTES I (PGM 111)
BTN
ATTRIBUTE/DISPLAY
DESCRIPTION
RANGE
DEFAULT
21
100-110 SERIAL DSS
(1:EN/0:DIS):ENABLE
Assigns Serial DSS usage authority.
0: Disable
1: Enable
Enable
22
100-110 DLTN (00-37)
DIAL TONE (00)
Each station can choose one of the below
dial tone sources
 00: dial tone,
 01: INT music
 02: EXT music,
 03: VSF MOH
 04~08: SLT MOH1~5,
 09~37: VSF MOH2~30
Refer to
description
dial tone
23
100-110 RBTN (00-37)
RING BACK TONE (00)
Each station can choose one of the below
ring back tone sources
 00: ring back tone
 01: INT music
 02: EXT music
 03: VSF MOH
 04~08: SLT MOH1~5
 09~37: VSF MOH2~30
Refer to
description
ring back
tone
24
100-110 ATTACH MSG
(1:ON/0:OFF) : ON
When e-mail notification of a new VSF
message is enabled (PGM 236-button 7), the
e-mail may include the voice mail as a wav
file attachment. VSF mail server IP (PGM
113-button18) &VSF Mail Address (PGM
113-button19) are required for proper
operation.
0: OFF
1: ON
ON
Table 3.3.3.2-2 STATION ATTRIBUTES II (PGM 112)
BTN
ATTRIBUTE/DISPLAY
DESCRIPTION
RANGE
DEFAULT
1
100-110 CALL TIME TN
(1:ON/0:OFF) : OFF
A tone can be sent periodically indicating the
elapsed time of an outgoing CO/IP call. The
Elapsed Call Timer (PGM 180-button 19)
determines the period between tones.
0: OFF
1: ON
OFF
2
100-110 AUTO HOLD
(1:ON/0:OFF) : OFF
Enables Auto Hold for the station. With Auto
Hold enabled, the system will place an active
external call on hold if the user presses a
CO/IP or DSS button.
0: OFF
1: ON
OFF
3
100-110 TIME RESTRICT
(1:ON/0:OFF) : OFF
The system can automatically disconnect
outgoing calls at the expiration of the Call
Restricttimer (PGM 180-button 14).
0: OFF
1: ON
OFF
4
100-110 IND CO ACCESS
(1:EN/0:DIS) : ENABLE
Permits stations to use dial codes to access
individual COLines.
0: Disable
1: Enable
Enable
