4.3.3.13 Linked Station Table – PGM 124
A station can be linked to another station so that the two stations effectively act as a single station with the
attributes of the primary station number.
An unregistered or registered station may be linked to a primary station. When unregistered station linking is
used, the linked station does not reduce the system’s capacity.
PROCEDURE
LINKED STA TABLE
ENTER STA NUMBER
Press the [PGM] button and dial 124.
STA 110 IS LINKED PAIR
PRESS FLEX KEY (1-3)
Use the dial-pad to enter the primary station number for the Linked pair.
(Ex. 110).
Press the desired Flex button.
Use the dial-pad to enter desired data. Refer to Table 3.3.3.13-1.
Press the [Save] button to store the data entry.
Table 3.3.3.13-1 LINKED STATION ATTRIBUTES (PGM 124)
BTN
ATTRIBUTE/DISPLAY
DESCRIPTION
DEFAULT
1
SET IP ADDRESS
IP: IP NOT ASSIGNED
IP Address of the linked station not required.
2
ROUTER IP ADDRESS
IP: ROUTER IP NOT ASSIGN
Set Router IP address associated with the linked
station.
3
STA 110: SET MAC ADDR
MAC: NOT ASSIGNED
Set MAC address of the linked un-registered station,
required data. Note the secondary station must not be
registered in the system prior to linking. If needed,
delete the device from the system.
