iPECS eMG80/100& eMG800 & UCP & vUCP
Administration and Programming Manual Issue 2.5
125
4.3.3.16 Station CCR Table – PGM 128
CCR Table can be assigned on a station basis. The description and valid inputs are given in Table 3.3.3.16-1.
PROCEDURE
ENTER PGM NUMBER
Press the [PGM] button and dial 128.
STATION CCR
ENTER STA RANGE
Enter Station Range (Ex. 100~110).
100-110 STA CCR
PRESS FLEX KEY (01-14)
Press the desired Flex button.
Press the desired Flex button; refer to Table 3.3.3.16-1.
Table 3.3.3.16-1 STATION CCR Table (PGM 128)
BTN
ATTRIBUTE/DISPLAY
DESCRIPTION
RANGE
DEFAULT
1-10
101 – 110 STA CCR
INPUT 0 : NOT ASSIGNED
Button 1 to 10 means outside user press
1 to 0. This dialing is matched with this
table destination.
The destination is 14 kinds.
NA
11
101 – 110CCR TBLUSAGE
(1:ON/0:OFF) : OFF
If this option is set to ON, this CCR table
is worked.
If this option is set to OFF, this CCR table
is not worked. Instead of that, the outside
caller’s dialed digit can be regarded as
DISA dialing.
OFF
ON
OFF
12
101 – 101 CCR 1 DGT ONLY
(1:ON/0:OFF) : OFF
If this option is set to ON, Only the first
digit that is user entered is affected by the
CCR routing.
If this option is set to OFF, the following
next digits are also affected by the DISA
routing.
ON/OFF
OFF
13
101 – 101 * USED AS
(0-3): NUMBERING PLAN
While listening to User Greeting, the *
button working is followed by this
attribute.
 0: Numbering Plan
 1: Replay Greeting
 2: Access Mail Box
 3: Leave Message
Refer to
description
Numbering
Plan
14
101 – 101 # USED AS
(0-3): ACCESS MAILBOX
While listening to User Greeting, the #
button working is followed by this
attribute.
 0: Numbering Plan
 1: Replay Greeting
 2: Access Mail Box
 3: Leave Message
Refer to
description
Access
Mailbox
