iPECS UCP600 - Page 579

iPECS eMG80/100& eMG800 & UCP & vUCP
Administration and Programming Manual Issue 2.5
138
Table 3.3.5.2-2 CO/IP ATTRIBUTES II (PGM 142)
BTN
ATTRIBUTE/DISPLAY
DESCRIPTION
DEFAULT
19
01-02 REJECT ANONYMOUS
(1:ON/0:OFF) : OFF
When REJECT ANONYMOUS “ON,” incoming calls
without Caller ID will be rejected.
OFF
20
01-02 PREFIX TABLE ID
(0-6) : 0
If prefix table ID is set to 0, then prefix dialing call cannot
be applied. If prefix table ID is set to (1-6), then prefix
dialing call can be applied with PREFIX DIALING
TABLE (PGM 206)
0
21
01-02 CO CUT OFF TMR
(00-99 MIN) : 00
Co base call cut-off timer can be set at this field.
00
22
01-02 DISA DELAY TMR
(0-9 SEC): 0
It is only used for Russia.
The system is immediately connected to a DISA call,
and a DISA announcement is played after this timer.
0
23
01-02 LDT TBT INDEX
(00-10) : 01
LCR will be operated with LDT table index.
1
24
01-02 DISA ANS TMR
(0-9 SEC) : 0
It is only used for Russia.
When DISA incoming call, the System is connected after
DISA Answer Timer.
0
Table 3.3.5.2-3 CO/IP ATTRIBUTES III (PGM 143)
BTN
ATTRIBUTE/DISPLAY
DESCRIPTION
DEFAULT
1
01-02 COLP TABLE IDX
INDEX : NOT ASSIGNED
When an incoming call on an ISDN Line is answered,
the system will send the caller id using the number from
the CLIP/COLP Table –PGM 201- entry defined by this
parameter.
None
2
01-02 CLIP TABLE IDX
INDEX : NOT ASSIGNED
When a call is placed on an ISDN Line, the system will
send the caller id using the number from the CLIP/COLP
Table –PGM 201- entry defined by this parameter. For
entry 00, the CLI STA NO entered in PGM 114-button 6
will be used in place of the station number. For other
entries, the station number is added as a suffix to the
entry in PGM 201.
None
3
01-02 ENBLOCKSENDING
(1:ON/0:OFF) : OFF
This entry determines if the system sends dialed digits
to the ISDN line as they are received (Overlap) or
collects all digits and forwards them in a block, enblock.
<Default>eMG80/100 : OFF,eMG800: ON
Refer ro
description
