iPECS eMG80/100& eMG800 & UCP & vUCP
Administration and Programming Manual Issue 2.5
163
Table 3.3.6.1-2 SYSTEM ATTRIBUTES II (PGM 161)
BTN
ATTRIBUTE/DISPLAY
DESCRIPTION
RANGE
DEFAULT
19
RECORD WARNING TONE
(1:ON/0:OFF) : ON
When call recording is active, a tone can
be sent to all connected parties to indicate
the conversation is being recorded.
0: OFF
1: ON
ON
20/21
UNUSED
Unused.
22
SMS CENTER NUMBER
.......................
When the PSTN is used to send SMS, the
phone number of the Short Message
Service Center must be entered.
23 digits
23
SMS PROTOCOL
(0-8) : NONE (0)
The Short Message Service Protocol must
be selected to support SMS:
 0: No PSTN SMS support
 1: ETSI-P1
 2: ETSI-P2
 3: KT-LivingNet
 4: SIP-Text
 5: SIP-XML
 6: KT-IP-PBX
 7: SKN-IP-PBX
 8:KT XML
0 ~ 8
NONE
24
SYSTEM 2 ADDED ATTR
PRESS FLEX KEY (1-23)
Select button 24 to access added
attributes 1~23.
FLEX 1 ~
FLEX 23
24-1
G722 PACKETIZATION(1ms)
(10/20/ 30) : 20
The G.722 voice frame packetization time
determines the interval at which voice
samples are packetized and sent when
the G.722 codec is used.
10/20/30ms
ec
20
24-2
UNUSED
This field is used only for KOREA.
24-3
SMS CENTER CLI
.......................
When the CO/IP is used to receive SMS,
the Caller ID expected from the Short
MSG Service Center must be defined.
23 digits
24-4
TRANSIT-OUT SECURITY
(1:ON/0:OFF) : ON
Check IP address for transit-out in the
master system, and if it is not a valid IP
address, it will be denied.
0: OFF
1: ON
ON
24-5
EMR CALL ATD NOTIFY
(1:ON/0:OFF) : ON
Provide notification to attendant when
user dials emergency number.
0: OFF
1: ON
ON
24-6
UNUSED
Unused.
