4.3.6.8 External Control Contacts – PGM 168
The MPBs include programmable contacts, which can be used to control external devices. Refer to Table 1.1-
1 System Capacity Chart for the number of available contacts. Each contact is assigned to activate under one
of several conditions. As a Loud Bell Contact (LBC), the contact will activate when the assigned station or
group receives an external call. Note for LBC that when the system is in the Night or Timed Ring mode, the
contact will activate for incoming UNA calls and ignore any station assignment. The contact may alternatively
activate as a Door open contact when External Page Zone 1 is accessed.
PROCEDURE
EXT CONTROL CONTACT
PRESS FLEXKEY (1-2 )
Press the [PGM] button and dial 168.
EXT CONTROL CONTACT
NO 1 : . . . (1-3)
Select Flex button 1~2 for the desired External Control contact.
Use the dial-pad to enter desired data.
- 1: LBC + station number
- 2: Door open
- 3: External Page 1 access
Press the [Save] button to store the External Contact data entry.
