4.3.6.9 LCD Display Mode -PGM 169
The LCD display mode sets the time (12/24 hr.), date (day/month order), language, and day-of-week display.
Refer to Table 3.3.6.9-1 and Table 3.3.6.9-2 for a description of the modes, the data entries required, and LCD
displays for each attribute.
PROCEDURE
LCD DISPLAY MODE
PRESS FLEX KEY (1-4)
Press the [PGM] button and dial 169.
Select the desired Flex button; refer to Table 3.3.6.9-1.
Use the dial-pad to enter the desired mode and language. Refer to
Table 3.3.6.9-1 and Table 3.3.6.9-2.
Press the [Save] button to store the LCD Display mode data entry.
Table 3.3.6.9-1 LCD DISPLAY MODE (PGM 169)
BTN
ATTRIBUTE/DISPLAY
DESCRIPTION
RANGE
DEFAULT
1
LCD DATE MODE
(1:MMDD/0:DDMM):MMDDYY
Sets the Date display as month/day or
day/month.
0: DD-MM-YY, 1: MM-DD-YY
Refer to
description
MMDDYY
2
LCD TIME MODE
(1:12H/0:24H):12H
Sets the Time display mode as 12 hour or
24-hour (military) time.
0: 24 Hour Mode, 1: 12 Hour Mode
Refer to
description
12 Hour
3
LCD LANGUAGE (00-18)
ENGLISH (00)
Sets the Language in the LCD used. Refer
to Table 3.3.6.9-2 below.
00~18
00
(English)
4
LCD WEEKDAY MODE (0-2)
PGM 169 BTN 1 (0)
Sets the Day-of-Week (DoW) display
mode:
0: no DoW, see PGM 169-BTN1
1: display MM/DD WDY, alpha month
display, overrides button 1.
2: display MM DD WDY, numeric month
display, overrides button 1.
Refer to
description
Use
button 1
Table 3.3.6.9-2 LCD LANGUAGE SELECTION
ENTRY
LANGUAGE
ENTRY
LANGUAGE
ENTRY
LANGUAGE
ENTRY
LANGUAGE
00
English
05
Danish
10
Portuguese
15
Turkish
01
Italian
06
Norwegian
11
Spanish
16
Polish
02
Finnish
07
Hebrew
12
Korean
17
Greek
03
Dutch
08
German
13
Estonian
18
Arabic
04
Swedish
09
French
14
Russian
