iPECS UCP600 - Page 636

iPECS eMG80/100& eMG800 & UCP & vUCP
Administration and Programming Manual Issue 2.5
195
Table 3.3.6.20-1 SYSTEM TIMERS I (PGM 180)
BTN
ATTRIBUTE/DISPLAY
DESCRIPTION
RANGE
DEFAULT
9
ACNR PAUSE TMR(sec)
(000-300) : 030
This timer establishes the time between
ACNR recall attempts.
000~300
seconds
030
10
ACNR RETRY COUNT
(01-13) : 03
This counter sets the number of recall
attempts for ACNR before ACNR is
abandoned. (For CIS: 1-9).
1~13
03
11
ACNR TONE DTC TMR(sec)
(001-300) : 030
If call progress tones are unavailable for
ACNR, the system will wait for this duration
after dialing before considering the called
party as busy/no answer.
001~300
seconds
030
12
AUTO RELEASE TMR(sec)
(000-300) : 030
If a user accesses a CO/IP path and does
not take any action, the system will
automatically release the CO/IP path when
this timer expires.
000~300
seconds
030
13
CCR INT DGT TMR(100ms)
(000-300) : 030
Inter-digit timer used with Customer Call
Routing function.
000~300
100msec
030
14
CALL RESTRICT TMR(min)
CHECK PGM 123-F2
Not used. Check PGM123-BTN2
00~99
minutes
00
15
CO DIAL DLY TMR(100ms)
(00-99) : 05
Delay for through connection to prevent
illegal dialing when CO/PBX has a slow
response.
00~99
100msec
05
16
RLS GUARD TMR(100ms)
(010-150) : 020
When a CO Line is returned to idle, the
system will deny access for this time to
assure the PSTN returns the CO circuitry to
idle.
010~150
100msec
020
17
CO RING OFF TMR(100ms)
(010-150) : 060
This timer sets the maximum ‘OFF’ duration
of the incoming ring cycle to determine
when a call has been abandoned.
010~150
100msec
060
18
CO RING ON TMR(100ms)
(1-9) : 2
This timer sets the ‘ON’ time of the
incoming ring cycle for the Ring Detect
circuitry of the system to recognize an
incoming call.
1~9
100msec
2
19
ELAPSED CALL TMR(sec)
(005-900) : 180
Users can receive a periodic tone indicating
the length of an outgoing call. This timer
sets the time before and between the
tones. Note Call Time Tone must be
enabled in PGM 112-button 1.
005~900
seconds
180
20
WEB PWD GUARD TMR(min)
(001-999) : 005
If no data packets are received during a
Web Admin connection for the Guard time,
the system will initiate a password check.
001~999
minutes
5
