4.3.6.22 DCOB SYS Timers – PGM 186
A number of timers can be assigned to control and affect the operation of E1 lines using R2 signaling. Refer to
Table 3.3.6.22-1 for the timer descriptions and inputs required.
PROCEDURE
DCOB SYS ATTRIBUTES
PRESS FLEX KEY (1-6)
Press the [PGM] button and dial 186.
Press the Flex button for the desired Timer; refer to Table 3.3.6.22-1.
Use the dial-pad to enter the desired Timer data. Refer to Table
3.3.6.22-1.
Press the [Save] button to store the Timer data entry.
Table 3.3.6.22-1 DCOB SYSTEM TIMERS (PGM 186)
BTN
ATTRIBUTE/DISPLAY
DESCRIPTION
RANGE
DEFAULT
1
R2 OUT MANAG TMR(sec)
(01-50) : 14
In R2 signaling, the maximum time
for waiting for the forward signal
from PBX.
01~50
(seconds)
14
2
R2 IN MANAG TMR(sec)
(01-50) : 14
In R2 signaling, maximum time for
waiting for forward signal from
PBX.
01~50
(seconds)
14
3
R2 DISAPPEAR TMR(sec)
(01-50) : 14
In R2 signaling, the maximum time
for waiting for the acknowledge of
R2 signal.
01~50
(seconds)
14
4
R2 PULSE TMR(20msec)
(01-30) : 07
In R2 signaling, time duration to
send pulse typed R2 signal.
01~30
(20 msec)
07
5
R2 READY TMR (20msec)
(000-500) : 007
Reserved for future usage for R2
timers.
000~500
(20 msec)
07
6
DIAL TONE DELAY (20msec)
(01-30) : 20
Reserved for future usage for R2
timers.
01~30
(20 msec)
20
