Call routing
223
System functions and features as of R4.1
syd-0570/1.2 – R4.1 – 08.2016
Step 2:
The system transmits the phone number in DTMF mode in accordance with the config-
ured conversion rule.
Fig. 107 Example 2: Network provider B is not integrated in the numbering plan of network provider A
Tab. 57 Example 2: Entry in the network provider table
Network pro-
vider
Exclude Access code Route
Conversion
rule
User ID PIN
Charge code
length
Network provider
B
Deactivated 0800123456 – EZ<3-># – – –
connect
0800 123456
331 22 33 44 55#
0-00 331 22 33 44 55
Network B
Network B
Communica-
tion server
LCR
User dials
DTMF mode
Network A
Communica-
tion server
LCR
Network A
