Mitel 430 - From the Private Leased-Line Network into the Private Leased-Line Network

Call routing
245
System functions and features as of R4.1
syd-0570/1.2 – R4.1 – 08.2016
6. 7. 3 From the private leased-line network into the private
leased-line network
A call from the private leased-line network will be routed on at the transit PINX in ac-
cordance with the information of the PISN destination user.
If the transit PINX is located in the same region as the destination user, the phone
number’s regional prefix will be truncated.
Fig. 120 Transit routing from the private leased-line network to another PISN user
Tab. 70 Routing parameter settings
Parameter Parameter value
Trunk group 4:
• Network interfaces Network interfaces in this trunk group
• Max. incoming calls Number of calls allowed simultaneously
• Maximum simultaneous connections Number of connections allowed simultaneously
• Network type Private
• Protocol QSIG or QSIG / PSS1 ISO
PINX 1 PINX 2
PINX 2
PINX 3
330
330
PISN
PISN
PISN user 330
User conguration
User conguration
Call Distribution Element 2
Route 2
DDI no.. -
Direct dialling plan 1
Trunk group 2 (PSS1)
Trunk group 4 (PSS1)
Changeover switches
Network
interfaces
FXO
BRI-T
PRI
BRI-T
PRI
S
extern
-> Direct dialling plan 1
-> Call distribution
element 2
-> User (330)
<- call no.
<- route 2
<- Trunk group 2
<- Network interfaces
