Mitel 430 - PISN-Internal Calls

Identification elements
94
System functions and features as of R4.1
syd-0570/1.2 – R4.1 – 08.2016
4. 7. 1 PISN-Internal Calls
Ordinary PISN-Internal Call
User C (340) on PINX 2 calls user A on PINX 1 by a direct route. Both users belong to
the same region.
Fig. 41 Example 1: User C calls user A (excerpt from Fig. 40)
Tab. 12 Example 1: Creating and presenting user C’s CLIP number
Step CLIP number NPI TON Description
1 340 PNP Level 0 User C → PINX 2
• There is no suitable DDI number.
2 50340 PNP Level 1 PINX 2
→ PINX 1
3 340 PNP Level 0 PINX 1
• The system’s own regional prefix is deleted
• TON is adapted.
4340 PINX1
→ user A
• Presentation on the system phone
340
340
340
C
A
201
50340
Destination PINX
Source PINX
PINX 2
PINX 1
