4. 7 Examples of CLIP Displays in the PISN
Various scenarios are used in a sample network to illustrate how CLIP displays are
handled in a PISN. Fig. 40 shows the sample network.
Fig. 40 Sample network: PISN with two regions and one virtual network user
