Call logging (CL)
310
System functions and features as of R4.1
syd-0570/1.2 – R4.1 – 08.2016
8. 7. 7. 1 PC1 format
This format covers requirements for direct transfer to a PC (PC1).
Format structure
Tab. 114 PC1 format
Example of PC1 format
The charge data is printed out every time the handset goes on-hook. This also applies
in cases where an external connection is forwarded.
Data field, meaning Structure Format Length Offset
Start of data record HT 1 0
User (cost centre) number
1)
1)
Dialling determines whether user No. or CC No. is displayed.
As a cost centre number this field can be 5 or 9 digits long. Depending on the configured cost centre length ≤
5 the field is 5 characters long. As of cost centre length ≥ 6 the length is 9 characters. With cost centre length
≥ 6, all the offsets following the cost centre are incremented by 4 characters.
ttttt I- SP 5 1
Sort character oo 00 -I 2 17
Date yymmdd 00 -I 6 10
Start time hh:mm 00 -I 5 17
Duration of connection hhHmmMss 00 -I 8 23
Primary channel group / trunk card number / net-
work interface number
2)
2)
The primary channel group is output in position "c", the trunk card number in position "bb" and the network in-
terface number in position "pp" (see example on page 307
).
cbbpp 00 -I 5 32
Number of metering pulses iiiii 00 -I 5 38
Call number dialled
3)
3)
If Data protection is configured, the last 4 digits of the number are replaced by the space character "SP".
zzzzzzzzzzzzzzzzzzzz I- SP 20 44
Serial number llll 00 -I 4 65
Carriage Return CR 1 69
Line Feed LF 1 70
