Identification elements
74
System functions and features as of R4.1
syd-0570/1.2 – R4.1 – 08.2016
Note:
For CLIP display on analogue terminals the following conditions have to be met:
– In the interface configuration ( =7g) the parameter Terminal supports call identification
must be activated.
– The terminal must support CLIP display.
– Restriction for Mitel 415/430: Different CLIPs can only be sent to 2 analogue terminals
simultaneously.
CLIP Numbers Outside the Registered Number Range
Sometimes the CLIP number transmitted to the public network is not within the regis-
tered number range Network providers have different ways of responding to this situa-
tion:
• The network provider uses the PINX master number as the CLIP number and sends
it on to the destination user.
• The network provider sends the CLIP number received, on to the destination user.
Usually this requires an agreement with the network provider (special arrangement).
In the following cases a PINX sends the CLIP outside the registered number range:
• If a freephone number (0800...) is to be displayed as the CLIP
• In the case of overflow routing via a different gateway PINX (see page 246
and ex-
ample in Tab. 16).
• In the case of break-out routing (see page 251
)
• If a break-in situation is to be forced
4. 2. 1 Displaying the CLIP
CLIP functions process incoming and outgoing calls.
Fig. 32 CLIP of an incoming and an outgoing call
D
C
B
A
Communi-
cation
server
C’s CLIP
A’s CLIP
