8. 7. 2 Data fields of the PC format
Tab. 86 shows the complete data record of a PC5 output. The data fields are listed in
their task sequence.
Tab. 86 PC5 format
8. 7. 2. 1 Explanation of the data fields
User number
Outgoing:
• Entry for the caller’s user number.
• Entry for source PINX and stand-alone communication server; otherwise the data
field remains empty.
Incoming:
• Contains an entry for destination PINX and stand-alone communication server; oth-
erwise the data field remains empty.
Data field Name Data format Formatting Length Offset
Start of data record:
Horizontal tab (HT) 10
User number NO i SP -I 12 1
Cost centre number CC i SP -I 9 14
Sort character SC i 0 -I 3 24
Date of start of connection DATE yymmdd 0 -I 6 28
Time of start of connection TIME hh:mm 0 -I 5 35
Duration of connection DURATION hhHmmMss 0 -I 8 41
Call charges CHARGES ddddddd.dd SP -I 10 50
Number of metering pulses METPUL i 0 -I 5 61
Channel group / trunk card / network
interface number
EXCH cbbpp 0 -I 5 67
Caller identification 1 ID1 i SP -I 20 73
Caller identification 2 ID2 i SP -I 20 94
Destination number 1 DEST1 i SP -I 40 115
Destination number 2 DEST2 i SP -I 40 156
Time-To-Answer TTA i 0 -I 3 197
Sequence number SEQ.NO. i 0 -I 3 201
Serial number SERIAL NO. i 0 -I 4 205
Carriage Return (CR) 1209
Line Feed (LF) 1210
