4. 7. 3 Incoming calls from the public network
User G on the public network calls user C on PINX 2 via PINX 1. He dials 055 555 55
54.
Fig. 46 Example 6: User G calls user C (excerpt from Fig. 40)
Tab. 17 Example 6: Creating and presenting user G’s CLIP number
Step CLIP number NPI TON Description
1 066 333 33 33 E.164 Unknown User G → Exchange → PINX 1
2 66 333 33 33 E.164 National PINX 1
• Prefix is truncated
• TON is set to National
3 66 333 33 33 E.164 National PINX 1
→ PINX 2
4 66 333 33 33 E.164 National PINX 2
• CLIP number is not altered.
5 0-066 333 33 33
1)
1)
In PINX 3’s trunk group configuration 066 666 60 is entered as the master number.
PINX 2 → user C
• Presentation on the system phone
340
C
G
066 333 33 33
0-066 333 33 33066 333 33 33 066 333 33 33
66 333 33 33
Destination PINX
PINX 2PINX 1
Gateway PINX
