Features
462
System functions and features as of R4.1
syd-0570/1.2 – R4.1 – 08.2016
9. 7. 12 Switch control outputs
Various equipment or installations can be controlled using control outputs on FXS inter-
faces or the ODAB options card (Mitel 415/430). The telephone can be used to operate
sun blinds, for example, or to switch the lighting on or off throughout the building.
Detailed Description
Tab. 297 Switch control outputs
Functions in prefix dialling
Tab. 298 Switch control outputs: Functions
Provided they have not already been defined, call numbers can be created in the num-
bering plan. Numbers already created can be deleted again or changed.
It is possible to view the control output status and to switch control outputs via
WebAdmin in the analogue interface configuration with the State (control output) pa-
rameter.
Tip:
Store function code under a function key
System configuration
Tab. 299 Controlling control outputs: System configuration
End point Operating sequence / signalling on the terminal Scope
A The user obtains an acknowledgement tone every
time he activates / deactivates the feature.
Possible interfaces:
The function is activated locally on the system.
Requirement:
Authorization is enabled in the user configura-
tion.
Functions Function codes
Activate control output *74 <Call number
1)
>
1)
call number assigned to this control output in the numbering plan
Deactivate control output #74 <Call number
1)
>
Parameter Remarks
Switch control outputs User's permission set
State (control output) Analogue interface configuration
Note: Function code and WebAdmin configuration are equivalent, i.e. the
change last made chronologically is the effective one.
