Mitel 430 - Examples of PC5 Output in a PISN

Call logging (CL)
299
System functions and features as of R4.1
syd-0570/1.2 – R4.1 – 08.2016
Transferred call, charge management deactivated
The entire call is logged in a single line. The connection duration is entered in the DU-
RATION field. The NR field contains the user number of the last user in the call. The
sort character is 320.
Tab. 99 ICL output for a call to a busy user
8. 7. 4 Examples of PC5 output in a PISN
Fig. 168 PISN with two regions and shared numbering plan for Region 50
NO CC SC DATE TIME DURATION CHARGES METPUL EXCH
202 320 020798 10:26 00H13M03 00101
ID1 ID2 DEST1 DEST2 TTA SEQ.NO. SERIAL NO.
0326242111 0326242111 01 007 58 0119
A
022 222 22 22
B
C
D
055 555 55 xx
066 666 66 xx
ICL
OCL
ICC
ICL
OCL
ICC
ICL
OCL
ICC
DDI: 60
DDI: 53
DDI: 50
Int. no. 250
Int. no. 300
Int. no. 250
Region 60
Region 50
PINX 3
PINX 2
PINX 1
