Call logging (CL)
300
System functions and features as of R4.1
syd-0570/1.2 – R4.1 – 08.2016
Tab. 100 Configuration of the PISN above
The following examples are based on this PISN.
Direct outgoing connection
A connection is set up directly to the public network using self dialling (cost type: busi-
ness).
Fig. 169 User B dials user A (0 022 222 22 22)
Tab. 101 OCL output on PINX 1
Outgoing connection via a gateway PINX
A connection is set up to the public network via a gateway PINX using self dialling (cost
type: business).
Numbering plan for
Separate prefix
code
Internal (local) users PISN users
PINX 1 50 200...299 3xx, 60xxx
PINX 2 50 300...399 2xx, 60xxx
PINX 3 60 200...299 50xxx
NO CC SC DATE TIME DURATION CHARGES METPUL EXCH
50250 010 180598 14:50 00H02m10 0.20 00002 00102
ID1 ID2 DEST1 DEST2 TTA SEQ.NO. SERIAL NO.
50 0222222222 0222222222 123
NO PISN number of user B.
SC Outgoing call to the public network. Self dialling network access, business.
ID1 Nothing is entered here as PINX 1 is both the source and gateway PINX.
ID2 Direct dial number via which user B can be reached directly from the public network.
DEST1,
DEST2
The number dialled by the user (DEST2) was forwarded unchanged by the PINX (DEST1) since LCR is
not activated.
A (022 222 22 22)
B (250)
PINX 1
DDI: 50
