Call logging (CL)
301
System functions and features as of R4.1
syd-0570/1.2 – R4.1 – 08.2016
Fig. 170 User C dials user A (0 022 222 22 22)
Tab. 102 OCL output on PINX 2 (source PINX)
Tab. 103 OCL output on PINX 1 (gateway PINX)
NO CC SC DATE TIME DURATION CHARGES METPUL EXCH
50300 010 180598 14:50 00H03m05 0.00 00000 00103
ID1 ID2 DEST1 DEST2 TTA SEQ.NO. SERIAL NO.
50300 0222222222 0222222222 5677
NO PISN number of user C.
SC Outgoing call to the PISN. Self dialling network access, business.
CHARGE
S, MET-
PUL
0 is entered here as the charges are incurred at PINX 1 and are not forwarded to PINX 2.
ID1 Nothing is entered here as PINX 2 is the source PINX.
ID2 PISN number of user C.
DEST1,
DEST2
The number dialled by user C (DEST 2) is forwarded unchanged by PINX1 (DEST 1) since LCR is not
activated.
NO CC SC DATE TIME DURATION CHARGES METPUL EXCH
040 180598 14:51 00H03m05 1.50 00015 00104
ID1 ID2 DEST1 DEST2 TTA SEQ.NO. SERIAL NO.
50300 53 107070222222222 0222222222 1235
NO Nothing is entered here as the caller is not a PINX 1 user.
SC Outgoing exchange-to-exchange call to the public network.
CHARGE
S, MET-
PUL
The call charges are entered here.
A (022 222 22 22)
C (300)
PINX 2
DDI: 53
PINX 1
