Call logging (CL)
302
System functions and features as of R4.1
syd-0570/1.2 – R4.1 – 08.2016
Direct incoming call
Fig. 171 User A calls user B (055 555 55 50)
Tab. 104 ICL output by PINX (destination PINX)
Incoming connection via a gateway PINX
Fig. 172 User A calls user C (055 555 55 53)
ID1 PISN number of user C.
ID2 DDI number via which user C can be reached from the public network.
DEST1,
DEST2
The number dialled by the user (DEST2) was converted into another call number (DEST1) by the LCR
function. This is the number actually dialled by PINX 1.
NO CC SC DATE TIME DURATION CHARGES METPUL EXCH
50250 321 180598 14:56 00H01m12 1.50 00015 00101
ID1 ID2 DEST1 DEST2 TTA SEQ.NO. SERIAL NO.
022222220 0222222222 50 0023 014 1236
NO PISN number of user B.
SC External call, answered directly.
ID1 User A wants to use this CLIP to present himself. It appears on user B’s system phone display.
ID2 Caller’s CLIP number verified by the public network. Displayed to the destination user only if no ID1
CLIP is available
DEST 1 Nothing is entered here with ICL output.
DEST 2 50 is user’s B direct dial number.
A (022 222 22 22)
B (250)
DDI: 50
PINX 1
A (022 222 22 22)
C (300)
PINX 1
DDI: 53
PINX 2
