Call routing
249
System functions and features as of R4.1
syd-0570/1.2 – R4.1 – 08.2016
Configuration example
Fig. 124 Configuration example of overflow routing via the public network
In PINX1’s numbering plan, the PISN users of PINX 2 are entered according to the
principle 60xxx.
The numbers of the internal users match with their direct dial numbers (user B has in-
ternal number 300 and direct dial number 300).
Setting LCR to PINX 1:
• The digit sequence "60" is entered in the LCR table:
All outgoing, PISN-internal calls whose phone number begins with "60" will be ana-
lysed by LCR.
• In the routing table the entry for the first network provider stays blank. However, an
alternative network provider is entered.
A
B
300
300
055 555 5x xx
066 666 6x xx
Region 60
PINX 1
PINX 2
Region 50
