Data service
260
System functions and features as of R4.1
syd-0570/1.2 – R4.1 – 08.2016
7. 4 User-to-user signalling (UUS)
The service "user-to-user signalling" allows users to exchange a limited volume of data
(128 bytes per user) among themselves over the signalling channel (D channel) during
the phase of connection set-up and clear-down. The exchange of data takes place
even if a call is not answered.
Requirements:
• Both users must have subscribed to the service with the network provider.
• The ISDN terminals or CTI applications used must support the service. System
phones do not support the service.
Scope
The communication server supports the service in variants 1 and 3 as per ETS 300
286, UUS1.
UUS is not supported in the private leased-line network and is only available at the
PINX which is connected to the public network.
Mitel Advanced Intelligent Network:
UUS is not supported in an AIN. The service is available only at the nodes that are connected to
the public network.
Call distribution element 2:
• Data-service destination table 2 (reference number of the data-service destination table)
Data-service destination table 2:
• Data service Fax 4 PISN user 330
User configuration PISN-BN 330:
• Route 2 (route reference number)
• Number Phone number to be dialled without exchange access prefix
Route 2:
• Trunk group 2 (reference number of one or more trunk group(s))
• External digit barring Use or do not use digit barring
• Max outgoing calls Number of calls going out simultaneously via this route
• Numbering plan identifier (NPI) PNP
• Type of number (TON) Unknown
Trunk group 2:
• Network interfaces Network interfaces of this trunk group
• Network type Private
• Protocol QSIG or QSIG / PSS1 ISO
Parameter Parameter value
