Call logging (CL)
311
System functions and features as of R4.1
syd-0570/1.2 – R4.1 – 08.2016
Fig. 176 CL output with PC1
8. 7. 7. 2 PC2 format
This format is an extension of the PC1 format. Here the cost centre number is also out-
put as a separate field, along with the DDI number.
Format structure
Tab. 115 PC2 format
Data field, meaning Structure Format Length Offset
Start of data record HT 1 0
User number ttttt |- SP 5 1
Cost centre number kkkkkkkkk |- SP 9 7
Sort character oo 00 -| 2 17
Date of start of connection yymmdd 00 -| 6 20
Time of start of connection hh:mm 00 -| 5 27
Duration of connection hhHmmMss 00 -| 8 33
Primary channel group / trunk card number / net-
work interface number
1)
cbbpp 00 -|542
DDI number
2)
ddddddddddd |- SP 11 48
Number of metering pulses iiiii 00 -| 5 60
Call number dialled
3)
zzzzzzzzzzzzzzzzzzzz |- SP 20 66
X
22 10 970504 07:22 00H00M13 00009 00003 167 0087
21 98 970504 07:22 00H00M04 00101 00000 01211111 0088
OIP
PC1
PC2
PC3
PC4
PC5
Protocol
Bill
Dialled numbersCall durationData in PC mode
(YYMMDD)
Network interfaceTime
Serial number
Sort character
Internal user number
Number of metering pulses
CL output
