9. 7. 13. 2 Open door
This function actuates the door opener of any door.
If the TFE is connected via an options card a relay which opens the door is activated
for three seconds.
If the door intercom system is connected via an analogue terminal port the correspond-
ing analogue port is called. When the call is answered by the TFE the configured
DTMF characters are transmitted automatically to open the door.
Detailed Description
Tab. 302 Open door
Functions / system configuration for connection via options card
Tab. 303 Opening doors: Function
Tab. 304 Opening doors: System configuration
Functions / system configuration for connection via analogue port
Tab. 305 Opening doors: Function
Tab. 306 Opening doors: System configuration
End point Operating sequence / signalling on the terminal Scope
A Once the feature has been activated, the user
obtains the acknowledgement tone.
Requirement:
Authorization is enabled in the user configura-
tion.
Function Function code
Open door *74 <Call No. of the door intercom system>
Parameter Scope / remarks
Release door Permission set of the user who wants to carry out the function.
Door intercom The number is defined in the numbering plan.
Function Function code
Open door *74 <Call number of the user who is assigned an analogue terminal to whose port the
door intercom system is connected>
Parameter Scope / remarks
Release door Permission set of the user who wants to carry out the function.
User The number is defined in the numbering plan.
DTMF sequence to open the door Analogue interface configuration
Note: The DTMF sequence must match the door opener sequence in the
TFE. If necessary, one or more pauses "P" can be entered before or within
the sequence. Each "P" represents a 1 s pause.
Example: PP1P2P3
