Mitel 430 - Call logging for outgoing calls (OCL)

Call logging (CL)
271
System functions and features as of R4.1
syd-0570/1.2 – R4.1 – 08.2016
Fig. 145 Complete report for all network interfaces
8. 3 Call logging for outgoing calls (OCL)
OCL is used to log the outgoing connection data of individual calls and output the data
via the system’s corresponding interface at the end of the call. OCL can be switched on
and off on the entire system ( Outgoing call logging (OCL)) and per user ( Journal).
Output formats
The PC1...PC5 output formats are available on a PC (Parameter OCL format).
For the output on a printer there is a choice of a list output (Protocol) or for each call
one multi-line invoice with additional text (Invoice).
With the OIP format, the call data can be sent to an OIP server and further processed
there.
Only the output formats Protocol and Invoice are subject to the surcharge calculator al-
located to the user.
Fig. 146 Schematic sequence
+
+
+
+
30.07.04 18:00
1822
2.1 01.07.04 18:05 4 21.10
2.2 27.05.04 13:00 27 78.30
3.1. . . 68 278.30
. 27.05.04 13:00 . .
. TOTAL 2763 4213.20
0.2 14.07.04 22:10 824 848.90
EXCH. LINES
CALL FEES
EXCH
CALLS
***** any text (max. 68 characters congurables) *****
FROM
FEE IN EURO
STATE
RECORD
SINCE
PC
PC1...PC5
Ethernet
Journal
printerOCL OFF
Output format
Output format
Protocol
Receipt
ON
OFF
OCL
per
user
Metering
pulses
