Call logging (CL)
305
System functions and features as of R4.1
syd-0570/1.2 – R4.1 – 08.2016
User data appears on the next line.
Example:
(see "Example of Protocol format", page 306
)
Data lines
Tab. 108 Data lines for protocol format
Content, meaning Structure Format Length
Print off-
set
Space SP 2 0
User (cost centre) number
1)
1)
Dialling determines whether user No. or CC No. is displayed. With exchange access 0 or 10, the user No. is
displayed; if exchange access is used with CC No. 13 or if there is a switch to the cost centre during the call
using *78, the CC No. is displayed. User numbers are always output with format "|- SP"; cost centre numbers,
always with format "00 -|".
As a cost centre number this field can be 5 or 9 digits long. Depending on the configured cost centre length ≤
5 the field is 5 characters long. As of cost centre length ≥ 6 the length is 9 characters. With cost centre length
≥ 6, all the offsets following the cost centre are incremented by 4 characters.
ttttt |- SP 5 2
Sort character ooo 00 -| 3 8
Date of start of connection ddmmyy 00 -| 6 12
Time of start of connection hh:mm 00 -| 5 19
Duration of connection hhHmmMss 00 -| 8 25
Trunk card number / network interface number /
primary channel group
2)
2)
The trunk card number is output in position "bb"; the network interface number in "pp"; and the primary chan-
nel group "c" in "c" (see example on page 306
).
bb.pp/c 00 -| 5 34
Charges ggggggg.gg SP -| 10 40
Call number dialled
3)
3)
If Data protection is activated, the last 4 digits of the number are replaced by "." (full stop) characters.
In Switzerland and other countries this applies to private calls (data protection for business calls never active);
in Germany, business calls (data protection for private calls never active).
zzzzzzzzzzzzzzzzzzzz |- SP 20 51
Serial number llll 00 -| 4 72
Carriage Return CR 1 76
Line Feed LF 1 77
