Call logging (CL)
314
System functions and features as of R4.1
syd-0570/1.2 – R4.1 – 08.2016
Example of PC4 format
Fig. 178 CL output with PC4
Depending on the number dialled by the user and the configuration in the LCR tables
the number actually dialled by the communication server may be different or identical.
X
31342 21168 10 970416 15:20 00H03M45 01002 34 00019 004988223211 004988223211 ... 0678
33031 90 970417 08:18 00H04M20 00201 00010 2430241 065243024 ... 0679
OIP
PC1
PC2
PC3
PC4
PC5
Protocol
Bill
Numbers dialled by
the user
Numbers dialled
by communica-
tion server for LCR
Data in PC
mode
(YYMMDD)
Call duration
Cost centre number
DDI No.
Trunk connections
TimeSort character Serial number
Number of metering pulses
Internal user number
CL output
