2. With the print side up, align all four sides of two paper stacks, and then load them next to
each other in the tray.
BBR024S
3. Carefully push the paper tray fully in.
Loading Paper into the Large Capacity Tray (LCT)
This section describes how to load paper into the large capacity tray (LCT).
• The large capacity tray (LCT) uses 8
1
/
2
× 11 paper exclusively. If you want to load A4 , or B5
JIS (Japanese Industrial Standard) , contact your service representative.
• Align the paper stacks and load them against the left and right walls, or a paper misfeed might occur.
• The tray can hold up to 1,200 sheets of paper. Do not stack paper over the limit mark.
1. Open the top cover of the large capacity tray (LCT).
BBR004S
2. Load the paper in the tray along the edge on the back.
Load the paper print side down.
Loading Paper
99
6
