Page #1060 background imageLoading...
Page #1060 background image
Scan Size
Select the size of the original to be scanned.
The following items and sizes can be selected:
[Auto Detect]
Scans original sizes using the automatic size detect function.
[Mixed Original Sizes]
Scans a batch of originals with different length by detecting the length of each.
[Custom Size]
Scans in a specified size.
Template size
A3
, A4 , A4 , A5 , A5 , B4 JIS , B5 JIS , B5 JIS , 11 × 17 , 8
1
/
2
× 14 , 8
1
/
2
× 13
, 8
1
/
2
× 11 , 8
1
/
2
× 11 , 5
1
/
2
× 8
1
/
2
, 5
1
/
2
× 8
1
/
2
• Selecting both [Mixed Original Sizes] and [Erase Border] reduces the scanning speed.
• You can specify original sizes of 140 mm (5.5 inches) or larger in [Custom Size].
Relationship of original of mixed sizes and scan size
This section explains differences you need to be aware of when scanning originals of different length (such
as A3 & A4 or B4 & B5) using the original position setting and size.
• If you select [Mixed Original Sizes], the machine detects the length of each original and scans them.
• If a template size is selected, the machine scans originals at the selected size regardless of the actual
size of originals. If an original is smaller than the selected size, the machine applies margins to the
scan area.
• If [Auto Detect] is selected for scanning originals from the exposure glass, the machine detects the
size of individual originals and scans accordingly.
• If only [Auto Detect] is selected for scanning originals from the ADF, the machine detects the size of
the first original and scans all the other originals based on that size.
• When scanning originals of different length at the same time, place them correctly by referring to the
chart below. The paper guides cannot be adjusted to small size originals, which may cause slightly
tilted scanning.
6. Various Scan Settings
124
6
