INPUT/OUTPUT CHECK MODE
C231/C237/C238 4-14 SM
Output Check Table
There are no differences from the C231 model in this section.
Code LCD Display Description
3
MOTOR: Master Eject
Out- 3
Turns on the master eject motor.
6
MOTOR: Vacuum
Out- 6
Turns on the vacuum fan motor.
7
MOTOR: Air Knife
Out- 7
Turns on the air knife fan motor.
8
SIG: Key Counter
Out- 8
Increments the key counter.
9
COUNTER: Master
Out- 9
Increments the master counter.
10
COUNTER: Paper
Out-10
Increments the paper counter.
12
MOTOR: Ink Supply
Out-12
Turns on the ink pump motor.
14
SOL: Print Pressure
Out-14
Turns on the pressure release solenoids.
At the same time, it turns on the paper transport
motor.
18
MOTOR: Paper Table
Down
Out-18
Turns on the paper table motor (down).
19
MOTOR: Paper Table
Up
Out-19
Turns on the paper table motor (up).
21
SIG: Fluorescent Lamp
Out-21
Turns on the xenon lamp.
22
MOTOR: Cutter
+ Direction
Out-22
Turns on the cutter motor.
23
MOTOR: Cutter
Home
Out-23
Turns on the cutter motor and moves the cutter
to the home position.
27
MOTOR: Drum Home
Stop
Out-27
Turns on the main motor and moves the drum to
the home position.
28
MOTOR: Drum Plot
Stop
Out-28
Turns on the main motor and moves the drum to
the master making position.
33
MOTOR: Original Feed
Out-33
Turns on the ADF motor.
34
MOTOR: Master Feed
High Speed
Out-34
Turns on the master feed motor at high speed.
