Service
Tables
INPUT/OUTPUT CHECK MODE
SM 4-15 C231/C237/C238
Code LCD Display Description
35
MOTOR: Master Feed
Low Speed
Out-35
Turns on the master feed motor at low speed.
36
MOTOR: Master Feed
Normal Speed
Out-36
Turns on the master feed motor at normal speed.
37
MOTOR: Scanner Turns on the scanner motor.
The scanner moves to the original scanning
position for ADF mode when the Start key is
pressed. It returns to home position when the
Start key is pressed again.
41
SIG: VHD on
Out-41
Applies thermal head voltage.
Power is applied by pressing the Start key. It is
stopped by pressing the Clear/Stop key.
42
MC: Paper Feed
Out-42
Turns on the paper feed clutch.
43
MOTOR: Paper
Delivery
Out-43
Turns on the paper transport motor while the
Start key is pressed.
44
MOTOR: Clamper
Close
Out-44
Turns on the clamper motor and moves the
clamper to the close position.
45
MOTOR: Clamper
Open
Out-45
Turns on the clamper motor and moves the
clamper to the open position.
46
MOTOR: Pressure
Plate ON
Out-46
Turns on the pressure plate motor and moves the
plate to the lower limit position.
47
MOTOR: Pressure
Plate OFF
Out-47
Turns on the pressure plate motor and moves the
plate to the home position.
