SCANNER
SM 3-5 C231/C237/C238
[C]: Lamp stabilizer (

x 2, 3 standoffs)
[D]: Scanner motor (

x 2,

x 1, 1 spring)
3.3.3 SCANNER H.P. SENSOR / PLATEN COVER SENSOR
•
Left scale, Upper scale, Exposure glass (

3.3.1)
•
Operation panel (

3.2.1)
•
Rear upper cover (

3.2.2)
[A]: Platen cover sensor (

x 1)
[B]: Left stay (

x 1)
[C]: Scanner H.P. sensor (

x 1)
C238R041.WMF
C238R042.WMF
C238R043.WMF
[C]
[D]
[A]
[B]
[C]
