SCANNER
C231/C237/C238 3-4 SM
3.3 SCANNER
3.3.1 EXPOSURE GLASS / SCALES
[A]: Left scale (

x 2)
[B]: Upper scale (

x 3)
[C]: Exposure glass
3.3.2 SBU AND LAMP STABILIZER / SCANNER MOTOR
•
Left scale, Upper scale, Exposure glass
(

3.3.1)
•
Upper right cover (

3.2.1)
[A]: SBU cover (

x 4)
[B]: SBU (

x 1,

x 5)
C238R038.WMF
C238R039.WMF
C238R040.WMF
[A]
[B]
[C]
[A]
[B]
