MECHANISM OVERVIEW
SM 6-5 C231/C237/C238
Solenoids
No. Component Function
46
Rear Pressure Release
Solenoid
Releases the press roller to apply printing
pressure.
21
Front Pressure Release
Solenoid
Releases the press roller to apply printing
pressure.
Counters
No. Component Function
25 Paper Counter Keeps track of the total number of copies.
26 Master Counter Keeps track of the total number of masters made.
Others
No. Component Function
11 Thermal Head Burns the image onto the master.
3 Exposure Lamp (Xenon Lamp) Applies light to the original for exposure.
