3.2.2 OPERATION PANEL
z Front cover ( 3.2.1)
[A]: Operation panel ( x 5,  x 2, = x 3)
3.2.3 REAR COVER
[A]: Rear cover ( x 9)
45
°
45
°
45
°
45
°
C267R002.WMF
C267R003.WMF
[A]
[A]
