COVERS
SM 3-3 C267
C267 Service
Manual
3.2.4 UPPER COVERS
[A]: Left upper cover ( x 2)
[B]: Top rear cover ( x 1)
[C]: Right upper cover ( x 1)
C267R004.WMF
[A]
[B]
[C]
