RuggedCom RuggedBackbone RX1500 User Manual

9. SNMP
ROX™ v2.2 User Guide 111 RuggedBackbone™ RX1500
Figure 9.12. SNMPv3 Target Configuration form
To display the SNMP Target Configuration form, navigate to admin/snmp/snmp-target-address/
{address}.
Target Name
A descriptive name for the target (ie. 'Corportate NMS')
enabled
Synopsis: boolean
Default: true
Enables/disables this specific target
Target Address
Synopsis: IPv4 address in dotted-decimal notation
Synopsis: IPv6 address in colon-separated hexadecimal notation
IPv4 or IPv6 address for the remote target.
Trap Port
Synopsis: unsigned short integer
Default: 162

RuggedCom RuggedBackbone RX1500 Specifications

General

Power Supply	Dual redundant, hot-swappable power supplies
Switching Capacity	Up to 128 Gbps
Operating Temperature Range	-40°C to +85°C
Mounting	DIN rail or panel mount
Certifications	IEEE 1613, IEC 61850-3, EN 50155, EN 50121-4
Power Input	24/48VDC or 110/220 VAC
Enclosure	Rugged metal
Type	Modular Layer 3 switch
