RuggedCom RuggedBackbone RX1500 User Manual

21. Modem
ROX™ v2.2 User Guide 206 RuggedBackbone™ RX1500
International Mobile Equipment Indentity
radio
Synopsis: A string
The current RF status of cellmodem
rssi-indicator
Synopsis: integer
The Received Signal Strength Indicator in dBm
network-operator
Synopsis: A string
The wireless network operator currently in use
network-in-use
Synopsis: A string
The network technology currently in use by the modem
network-status
Synopsis: A string
The registration status of the modem with the wireless network
sim
Synopsis: A string
The Subscriber Indentity Module number
The following information provides additional details about the fields in the Edge Cellular Modem
Information Form.
Rssi Indicator (Received Signal Strength) indicates the signal level received by the cellular modem from
the cell site.
Network Operator displays the identity of the wireless network provider to which the cellular modem
is currently connected.
Network Status displays the current registration status of the cellular modem with respect to the cellular
network. Possible values are:
• Registered, home
• Registered, roaming
• Unregistered
SIM displays the ID of the SIM card currently installed in the cellular modem.
21.1.2.3. Global Cellular Modem GSM Configuration
Figure 21.4. Global Cellular GSM menu
HSPA and Edge data is configured from the Global Cellular GSM menu.

RuggedCom RuggedBackbone RX1500 Specifications

General

Power Supply	Dual redundant, hot-swappable power supplies
Switching Capacity	Up to 128 Gbps
Operating Temperature Range	-40°C to +85°C
Mounting	DIN rail or panel mount
Certifications	IEEE 1613, IEC 61850-3, EN 50155, EN 50121-4
Power Input	24/48VDC or 110/220 VAC
Enclosure	Rugged metal
Type	Modular Layer 3 switch
