RuggedCom RuggedBackbone RX1500

12. Chassis Management
ROX™ v2.2 User Guide 127 RuggedBackbone™ RX1500
The name of the power module slot as labeled on the chassis
MOV Protection
Synopsis: string - one of the following keywords { damaged, working, na }
The state of the MOV protection circuit
PM Temperature (C)
Synopsis: integer
The temperature (Celsius) inside the power module
PM Current (mA)
Synopsis: integer
The current (mA) sourced by the power module
PM Voltage (mV)
Synopsis: integer
The voltage (mV) sourced by the power module
12.2. Slot Hardware
Figure 12.6. Slot Hardware table
Figure 12.7. Slot Hardware form
The Slot Hardware table and form contain identifying information about the hardware module installed
in a particular chassis slot.
slot
Synopsis: string - the keyword { --- }
Synopsis: string - one of the following keywords { main, pm2, pm1 }
Synopsis: string - one of the following keywords { lm6, lm5, lm4, lm3, lm2, lm1, sm }
Synopsis: string - one of the following keywords { em, cm }
