20. Link Aggregation
ROX™ v2.2 User Guide 200 RuggedBackbone™ RX1500
Figure 20.8. Trunk Ports table
Figure 20.9. Trunk Ports Table in Edit Private Mode
To display the forms and tables below, click on interface/trunks/{number}. Most can also be accessed
by clicking on interface/switch/{line module}.
Figure 20.10. Key Settings
Figure 20.11. Ethernet Trunk Interfaces form
Trunk ID
Synopsis: integer
The trunk number. It doesn't affect port trunk operation in any way and is only used for identification.
Switchport
Synopsis: boolean
Default: true
The physical port into either Switched mode or a dedicated Routing mode.
alias
Synopsis: A string
The SNMP alias name of the interface
Figure 20.12. Multicast Filtering form
