RuggedCom RuggedBackbone RX1500 User Manual

22. Serial Protocols
ROX™ v2.2 User Guide 229 RuggedBackbone™ RX1500
turnaround
Synopsis: integer
Default:
The amount of delay (if any) to insert between the transmissions of individual messages out the
serial port
call-direction
Synopsis: string - one of the following keywords { both, out, in }
Default: out
Whether to accept an incoming connection, place an outgoing connection or do both
max-connection
Synopsis: integer
Default: 1
The maximum number of incoming connections to permit when the call direction is incoming.
remote-ip
Synopsis: IPv4 address in dotted-decimal notation
The IP address used when placing an outgoing connection.
remote-port
Synopsis: integer
The TCP destination port used in outgoing connections
local-port
Synopsis: integer
The local TCP port to use to accept incoming connections.
22.2.3. Setting TcpModbus
Figure 22.10. TCP Modbus Configuration form

RuggedCom RuggedBackbone RX1500 Specifications

General

Power Supply	Dual redundant, hot-swappable power supplies
Switching Capacity	Up to 128 Gbps
Operating Temperature Range	-40°C to +85°C
Mounting	DIN rail or panel mount
Certifications	IEEE 1613, IEC 61850-3, EN 50155, EN 50121-4
Power Input	24/48VDC or 110/220 VAC
Enclosure	Rugged metal
Type	Modular Layer 3 switch
