38. Firewall
ROX™ v2.2 User Guide 450 RuggedBackbone™ RX1500
Zone
Synopsis: A string
A pre-defined zone
Interface
Synopsis: A string
A pre-defined interface to which optional IPs and/or networks can be added
IP Address List
Synopsis: string
(Optional) Additional IP addresses or networks - comma separated
Figure 38.15. Host Options form
IPsec zone
Synopsis: boolean
Default: false
38.5.6. Policies
Figure 38.16. Main Policy Settings table
Figure 38.17. Main Policy Settings form
Default actions for connection establishment between different zones. Configuration of the default
actions for traffic between different firewall zones. They can be overridden for particular hosts or types
of traffic by defining specific rules.
Policy Name
Synopsis: string
Enter a name tag for this policy
Policy
Synopsis: string - one of the following keywords { continue, reject, drop, accept }

RuggedCom RuggedBackbone RX1500 Specifications

General

Power Supply	Dual redundant, hot-swappable power supplies
Switching Capacity	Up to 128 Gbps
Operating Temperature Range	-40°C to +85°C
Mounting	DIN rail or panel mount
Certifications	IEEE 1613, IEC 61850-3, EN 50155, EN 50121-4
Power Input	24/48VDC or 110/220 VAC
Enclosure	Rugged metal
Type	Modular Layer 3 switch
