RuggedCom RuggedBackbone RX1500 User Manual

38. Firewall
ROX™ v2.2 User Guide 449 RuggedBackbone™ RX1500
routefilter
Enables route filtering
proxyarp
Enables proxy ARP
maclist
Not currently implemented
nosmurfs
Packets with broadcast address as source are dropped and logged at info level
logmartians
Enables logging of packets with impossible source addresses
Figure 38.12. Broadcast Address form
broadcast-addr
(Optional) A broadcast address
38.5.5. Host Configuration
Hosts are used to assign zones to individual hosts or subnets, on an interface which handles multiple
subnets.
Figure 38.13. Main Host Settings table
Figure 38.14. Main Host Settings form
name
Synopsis: string
The name of a host configuration entry

RuggedCom RuggedBackbone RX1500 Specifications

General

Power Supply	Dual redundant, hot-swappable power supplies
Switching Capacity	Up to 128 Gbps
Operating Temperature Range	-40°C to +85°C
Mounting	DIN rail or panel mount
Certifications	IEEE 1613, IEC 61850-3, EN 50155, EN 50121-4
Power Input	24/48VDC or 110/220 VAC
Enclosure	Rugged metal
Type	Modular Layer 3 switch
