RuggedCom RuggedBackbone RX1500 User Manual

30. Network Discovery
ROX™ v2.2 User Guide 346 RuggedBackbone™ RX1500
30.2. LLDP Parameters
Figure 30.2. Net-discovery LLDP menu
The Net-discovery LLDP menu is accessible from the main menu under switch. The path to this menu
is switch/net-discovery/lldp. The LLDP form, LLDP Global Statistics Form and LLDP Local System form
appear on the same screen as the menu.
Figure 30.3. LLDP form
This form is used to configure the Network Discovery Protocol (LLDP).
Enabled
Synopsis: boolean
Default: true
Enables the LLDP protocol. Note that LLDP is enabled on a port when LLDP is enabled globally
and along with enabling per port setting in Port LLDP Parameters menu.
Transmission Interval (sec)
Synopsis: integer
Default: 30
The interval at which LLDP frames are transmitted on behalf of this LLDP agent.
Transmission Hold
Synopsis: integer
Default: 4

RuggedCom RuggedBackbone RX1500 Specifications

General

Power Supply	Dual redundant, hot-swappable power supplies
Switching Capacity	Up to 128 Gbps
Operating Temperature Range	-40°C to +85°C
Mounting	DIN rail or panel mount
Certifications	IEEE 1613, IEC 61850-3, EN 50155, EN 50121-4
Power Input	24/48VDC or 110/220 VAC
Enclosure	Rugged metal
Type	Modular Layer 3 switch
