RuggedCom RuggedBackbone RX1500 User Manual

34. Dynamic Routing
ROX™ v2.2 User Guide 418 RuggedBackbone™ RX1500
34.5.1.3. Neighbor
Neighbors are other BGP routers with which to exchange routing information. One or more neighbors
must be specified in order for BGP to operate.
If BGP Neighbors are specified but no Networks are specified, then the router will receive
BGP routing information from its neighbors but will not advertise any routes to them.
Neighbor IP address
Synopsis: IPv4 address in dotted-decimal notation
The neighbor IP address.
Neighbor Autonomous System ID
Synopsis: unsigned integer
A BGP neighbor.
ebgp-multihop
Synopsis: unsigned byte integer
The maximum hop count. This allows EBGP neighbors not on directly connected networks.
Maximum Prefix
Synopsis: unsigned integer
The maximum prefix number accepted from this peer.
next-hop-self
Disables the next hop calculation for this neighbor.
password
Synopsis: A string conforming to: "[^\s]+"
Password.
soft-reconfiguration
Per neighbor soft reconfiguration.
weight
Synopsis: unsigned short integer
The default weight for routes from this neighbor.
Route Map
in
Synopsis: A string conforming to: "[^\s]+"
Apply route map to incoming routes
out
Synopsis: A string conforming to: "[^\s]+"
Apply route map to outbound routes.
34.5.1.4. Aggregate-address
Aggregate Network
subnet
Synopsis: IPv4 address and prefix in CIDR notation
subnet (xxx.xxx.xxx.xxx/xx).

RuggedCom RuggedBackbone RX1500 Specifications

General

Power Supply	Dual redundant, hot-swappable power supplies
Switching Capacity	Up to 128 Gbps
Operating Temperature Range	-40°C to +85°C
Mounting	DIN rail or panel mount
Certifications	IEEE 1613, IEC 61850-3, EN 50155, EN 50121-4
Power Input	24/48VDC or 110/220 VAC
Enclosure	Rugged metal
Type	Modular Layer 3 switch
